Characteristics

✔ Manufactured in compliance with the requirements of European Directive 2014/68/EU on Pressure Equipment, Module H.

✔ Face-to-face distance according to the following standards:

• NF EN 558-1 Series 20
• ISO 5752 Series 20
• DIN 3202

Functions

✔ Mounted between flanges PN 10 / PN 16, compliant with:

• EN 1092-2
• BS 450
• AISI B16.1-5

✔ Adjustable for mounting between flanges according to:

• ASME B16.5 Class 150
• JIS 10K
• GOST PN10/16

✔ Pressure tests compliant with the following standards:

• EN 12266-1
• DIN 3230
• BS 6755
• ISO 5208

✔ Test pressure:

• Body: 24 bar
• Seat: 17.6 bar
